BL2418 B2418M 24mm inner rotor small BLDC Brushless DC Motor

BL2418 B2418M 24mm inner rotor small BLDC Brushless DC Motor

Item No.: BL2418 B2418M

BL2418i integrated electronics pricing, we offer BL2418 24 mm small inner rotor brushless dc electric motor specs custom, OEM service.

motor case diameter: 24 mm

motor case length: 18 mm

motor case shape: round motor shell

brush type: brushless

motor type: single bldc motor

bearing type: bushing/ball bearing

manufacturer: FONEACC MOTOR

INQUIRY

BL2418i specs

Description

BL2418 B2418M 24mm inner rotor small BLDC Brushless DC Motor

Specifications:

Size: Ø24.0* 18.0mm
Built-in driver
PWM pulse wide speed range
Clockwise/counter-clockwise rotation
FG speed feedback signal
Low EMC
Low noise
Long life: 20000hrs Min.
Over-current protection
Over-voltage protection
Under-voltage protection
OEM and ODM orders are welcome
The design can be customized

Applications:
Personal care, home application, industry apparatus, business equipment, and medical apparatus

Samples can be sent on your request.

Images of BL2418 bldc motor:

BL2418

Output Power: 1W~6W

Weight: 30g (Approx.)

Brushless DC Motor-Typical Application

Home Application:

White Goods, Small Appliance, Small Fanner, Electric Cooker

Medical Apparatus:

Medical Pump, Medical Stirrer, Centrifugal Machine

Industry Apparatus:

Electric Valve, Portable Screwdriver, Air/Water/Vacuum Pumps

Business Equipment:

Printer, Copier, Projector, Scanner, Cash Register, Card Sender

Personal Care:

Hair Curler, Hair Straighter, Hair Dryer, Electric Shaver, Massager, Vibrator

Model	Voltage(V)		No Load		Rated Load				Stall
Model	Operating Range	Rated	Speed (rpm)	Current (A)	Torque (mNm)	Speed (rpm)	Current (A)	Output P. (W)	Torque (mNm)	Current (A)
BL2418-S01	3~9	6	9260	0.21	2.45	7490	0.61	1.93	6.2	1.2
BL2418-S02	8~16	12	6520	0.08	2.45	4660	0.24	1.2	8.4	0.65
BL2418-S03	8~26	12	12420	0.127	2.94	9580	0.43	2.96	12.8	1.47
BL2418-S04	8~26	24	12770	0.065	5.89	9280	0.41	5.72	21.5	1.32
BL2418-S05	8~26	24	8660	0.055	2.94	6690	0.169	2.06	12.8	0.55

Characteristics: CW & CCW, Signal function available, Locked rotor protection, Stepless speed regulation, Low noise, Low EMI, Long life 5000-50000hrs

Notice: Data in this typical specification sheet are for other certain customers. Voltage, rated torque, speed, current, power, and shaft extension feature & dimension can be changed to meet the customer-specific requirements.

Outline Drawing: Usable machine screw length 1.5mm max from motor mounting surface Unit: Millimeter
